Quick Details

  • Condition: New
  • Place of Origin: Henan, China (Mainland)
  • Brand Name: SANQ
  • Model Number: JS2000
  • Mixing Power: 2*55kw
  • Charging Capacity: 4800L
  • Reclaiming capacity: 3000L
  • Speed of Mixing Drum: 23.1r/min
  • Water Supply Mode: Water Pump
  • Working Cycle Period: 60-72S
  • Discharge Way: Pneumatic or manual
  • Outline Dimension: 10907*3490*12350mm
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Capacity: 90-120m3/h
  • Number of mixing blade: 7 x 2
  • Hoist Electromotor Power: 21kw
  • Water Pump Power: 3kw
  • Lifting speed of hopper: 24.58m/min
  • Max aggerate size: 60mm
  • Discharge height: 3800mm
  • Loading type of aggregates: Hopper
  • Overall weight: 14000kgs

Packaging & Delivery

Packaging Details 1 x 20FR
Seaworthy package
Delivery Time 10-35 days

Dischanrge Volume 2000L Stationary Concrete Mixer for sale



Product Description

1-Introduction-Concrete mixer



  • SANQ GROUP has started production of Concrete Mixer since 1990 and win much reputation for China project contractors and owners and also overseas
  • JS series concrete mixer is compulsory twin-shafts concrete mixer, which is composed of feeding system, discharging system, water supply system and electrical system and mainly used to produce commodity concrete, such as hard concrete, plastic concrete, fluid concrete, various mortars, etc
  • The twin-shafts concrete mixer can not only work independently, but also can be adopted as the mixer in the concrete batching plant.
  • The concrete twin shaft mixer has the advantages like high efficiency, good mixing, easy to install, no leakage problem, less maintenance work, etc.
  • JS series concrete mixers are double horizontal axle forced mixers with two advantages of independent performance or forming simple concrete mixing plants with PLD series of batching machines-- Twin Shaft Concrete Mixer
  • They can also offer matched main engine for mixing plants applicable to various sizes of precast plant as well as industrial and civil construction works roads,bridges,water works,and harbors.
  • The can mix dry hard concrete ,elastic concrete ,flow concrete ,light aggregate concrete an various mortars,high efficient and used very widely.









2-Advantage-- concrete mixer



The twin shaft concrete mixer has strong mixing ability, the mixing quality is better and the production-efficiency is high.





  • Equipe with multiple shaft end sealing protection device and wind pressure sealing protection device and effectively avoid leakage absolutely;
  • Monitoring system of mixer can working condition of monitor reduction box,dischage pump and lubricating pump;
  • Equip with special-purpose motor lubricate oil pump, and four separate pump core respectively feeds oil to four axial heads directly,without using by-pass valve;
  • Multi pipes & way water injecting system can make sure that water can injected uniformly;
  • Heavy design and stable running.



 3-Parameter-- concrete mixer

MODELJS2000
Capacity 90-120m³/h
Discharge Volume2000L
Charge Volume3000L
Mixing blade speed23.1r/min
Number of mixing blade 7×2
Mixer motor power74kw
Hoist Electromotor power21kw
Water pump power3kw
Lifting speed of hopper24.58m/min
Max aggregate size60mm
Discharge height3800mm
Overall weight:14000Kg
Overall dimensional(L*W * H)10907*3490*12350mm



 4-Application-- concrete mixer

 They can also offer matched main engine for mixing plants applicable to various sizes of precast plant as well as industrial and civil construction works roads,bridges,water works,and harbors.The can mix dry hard concrete ,elastic concrete ,flow concrete ,light aggregate concrete an various mortars,high efficient and used very widely.

This unit can not only be used separately but also used as a mixing building .This host machine available for this unit can be used for  common building works,road &bridge works and small-sized structural part shops.







Company Information

 1-Indtroduction-- concrete mixer

  • Zhengzhou Sanqgroup Machinery and Equipment Co., Ltdare professioanl manufacturer which specialize in R&D, production, distribution and services of concrete equipment. Sanqgroup are located in west of Zhengzhou, the capatial city of Henan province,Covers an area of 45000 square meters with more than 8000 square meters of morden workshop.
  • Sanqgroup has absorbed Europe, Japan, the United States and other international advanced technology, with The world's leading batching plant electrical control system we are dedicate to manufacturing high qualtiy, high efficiency and High environmental protection products.
  • Our main products are concrete mixing plant, JS series twin shaft mixer, concrete pump,concrete trailer pump and asphalt mixing plant. our products have been exported to Vietnam, Indonesia, Malaysia, India Iran, UAE, Saudi Arabia, Yemen, Algeria, Nigeria, Togo, Benin, Russian, KZ, Mongolia, Chile and Peru etc.have owned favourable reputation in the international market.








2-Our Team-- concrete mixer



Zhengzhou Sanqgroup Machinery & Equipment Co., Ltd. is a production and sales enterprise, the company's business is flourishing now, mainly due to our energetic team.

  • Technology team:
Technology team is consisted of 11 persons, 3 are senior engineers, 8 are engineers. The average age is about 35 years old. 2 are doctor degree, 4 are master degree and 5 are bachelor degree.
  • Sales team:
Sales team is composed of 15 persons, 10 for English market, 5 for Russian market. 80% is Bachelor and 20% is junior college. The average age is 26 years old. It is a highly educated, high-quality, young and energetic team.
  • Production Team:
Workers are divided into general worker and skilled worker. All skilled workers have some certificates for technical proficiency with work experience from 2 to 20 years. All general workers will be strictly trained by skilled worker after recruit according to their post for 2-3 weeks and then can operate after passing examination.

Packaging & Shipping

  Export standard container-20GP or 40GP, 40HQ,FR container in bulk, the spare parts in wooden or iron case according to the size and weight.









Certifications





Our Services

1-after-sales service- concrete mixer

SANQGROUP has established an integrated marketing system consisting of "Sales,Maintenance ,Fitting ,Information and Advgertisement "based on the market-oriented policy as well as the high quality products,perfect services and good faith for market development and therefore the marketing network has covered every port of the world. We consider customers the most important element for creating the enterprise's benefit. Sanqgroup have received users' recognition for the perfect services. We will always keep our promise for customer in any ports of the word sice we do what we planced.

  • 24 hours on line sercvice
  • Regular after-sale visit
  • All after -sale service problem will be solved in 72 hours
  • Accessories gloabally supply
  • Lifetime technique suport
  • Enginnerserve overseas avaiable
2-Spare Parts and Service-- concrete mixer
Sanqgroup deliver solutions tailored to each customer's requirments.We set great store by advising and working with our customers right from first contact to plant commissioning.Our in-house technical deparment ensures clarification of all technical issues and thoroughly prepares all project drawings. After cpmmissoning of the plant we are happy to provide advice to ensure that the plant always fuctions in the best possible way an has long lifespan.
SANQGROUP has a complete spare parts supply system ,equipped with skilled professional and technical personnel ,to provide clients with pure spare part sand thoughtful service 7*24 hours every day.
