Quick Details

  • Condition: New
  • Power Type: Electric
  • Place of Origin: Henan, China (Mainland)
  • Brand Name: SANQ
  • Model Number: HBTS90-20-180
  • Power(W): 90*2KW
  • Weight: 7000KG
  • Dimension(L*W*H): 7000*2300*2600
  • Certification: CE
  • Warranty: 12 Months after Installation
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Product Name: Putzmeister Concrete Pump
  • Hydraulic system type: open type
  • Motor speed: 1480r/min
  • Hydraulic system pressure: 32Mpa
  • Power: 180nkw
  • Max Concrete throughput: 95m³/h

Packaging & Delivery

Packaging Details 1 x 20GP Seaworthy package
Delivery Time 20 days after order

Used Putzmeister Concrete Pump

Product Description



Introduction:



  Concrete pumps is a concrete machine to replace the traditional way to lift the concrete by labor force but pumps the concrete through the pipeline, use as conveniently as the tap water.



 1. The main oil pump adopt Japanese Kawasaki oil pump;

 2. Two ways to convey concrete: high-pressure with small volume and low-pressure with large volume;

 3. Diesel trailer concrete pump adopts the air-cooled and water-cooled motor;

 4. Italy MANULI high-pressure hose is used to ensure the security of hydraulic system, without leakage;

 5. Pumping fuel tank with an unique waterproof structure and with the combination of discharging and blocking, so it has anti-emulsified activit







Parameter:

MODELHBTS90-20-180
Maximum concrete throughput90M³/H
Maximum output pressure9/5Mpa
Hydraulic system type Open type
Hydraulic system pressure32Mpa
Motor speed1480r/min
Motor power75KW
The main oil pump rated working flow281L/min
Pumping oil cylinder bore/strokeø 125mm /1400mm
Concrete cylinder bore/strokeø 200mm /1400mm
High-low pressure switchWith
Hydraulic oil tank volume500L
Bucket volume0.8M³
Feeding height1100mm
Maximum Theoretic conveying distance320m/1380m
Concrete slump120~230mm
Overall dimension(L×W×H)6000mm*2160mm*2300mm
Weight6150kg

Detailed Images

 Feature:

  1. The distribution valve adopts the advanced S pipe valve system, good sealing performance; the structure is simple and reliable, and convenient replacement of the wearing parts;
  2.  Highabsorption optimize the hopper structure, improve teh regional structure inside of the hopper which affects the suction performance;
  3. Mixing blade with unique design and few deal space so it can be adapted to a wide range of concrete formula;
  4.  The main electrical components are imported, they fully guarantee the electrical control system of high reliability;
  5. Perfect maintainability and dismandtling of all wearing parts are very convenient.













Trade Shows

 Our concrete pump have exported to  Benin







Company Information

1-Indtroduction

  • Zhengzhou Sanqgroup Machinery and Equipment Co., Ltdare professioanl manufacturer which specialize in R&D, production, distribution and services of concrete equipment. Sanqgroup are located in west of Zhengzhou, the capatial city of Henan province,Covers an area of 45000 square meters with more than 8000 square meters of morden workshop.
  • Sanqgroup has absorbed Europe, Japan, the United States and other international advanced technology, with The world's leading batching plant electrical control system we are dedicate to manufacturing high qualtiy, high efficiency and High environmental protection products.
  • Our main products are concrete mixing plant, JS series twin shaft mixer, concrete pump,concrete trailer pump and asphalt mixing plant. our products have been exported to Vietnam, Indonesia, Malaysia, India Iran, UAE, Saudi Arabia, Yemen, Algeria, Nigeria, Togo, Benin, Russian, KZ, Mongolia, Chile and Peru etc.have owned favourable reputation in the international market.

2-Our Team



Zhengzhou Sanqgroup Machinery & Equipment Co., Ltd. is a production and sales enterprise, the company's business is flourishing now, mainly due to our energetic team.

  • Technology team:
Technology team is consisted of 11 persons, 3 are senior engineers, 8 are engineers. The average age is about 35 years old. 2 are doctor degree, 4 are master degree and 5 are bachelor degree
  • Sales team:
Sales team is composed of 15 persons, 10 for English market, 5 for Russian market. 80% is Bachelor and 20% is junior college. The average age is 26 years old. It is a highly educated, high-quality, young and energetic team.
  • Production Team:
Workers are divided into general worker and skilled worker. All skilled workers have some certificates for technical proficiency with work experience from 2 to 20 years. All general workers will be strictly trained by skilled worker after recruit according to their post for 2-3 weeks and then can operate after passing examination.


Certifications









Our Services



1-After-Sales Service

SANQGROUP has established an integrated marketing system consisting of "Sales,Maintenance ,Fitting ,Information and Advgertisement "based on the market-oriented policy as well as the high quality products,perfect services and good faith for market development and therefore the marketing network has covered every port of the world. We consider customers the most important element for creating the enterprise's benefit. Sanqgroup have received users' recognition for the perfect services. We will always keep our promise for customer in any ports of the word sice we do what we planced.

  • 24 hours on line sercvice
  • Regular after-sale visit
  • All after -sale service problem will be solved in 72 hours
  • Accessories gloabally supply
  • Lifetime technique suport
  • Enginnerserve overseas avaiable
2-Spare Parts And Service
Sanqgroup deliver solutions tailored to each customer's requirments.We set great store by advising and working with our customers right from first contact to plant commissioning.Our in-house technical deparment ensures clarification of all technical issues and thoroughly prepares all project drawings. After cpmmissoning of the plant we are happy to provide advice to ensure that the plant always fuctions in the best possible way an has long lifespan.
SANQGROUP has a complete spare parts supply system ,equipped with skilled professional and technical personnel ,to provide clients with pure spare part sand thoughtful service 7*24 hours every day.
